Product Description:
Hawks Motorsports is pleased to offer our clients the 82-92 Camaro/Firebird SBC 3/8"-16 Pressure Plate Bolts, ARP 130-2201. This ARP High Performance Series pressure plate bolt kit is designed for compatible Chevrolet Small Block V8 clutch applications and includes six 3/8"-16 hex-head bolts with washers. The bolts are manufactured from premium-grade chromoly and hardened to a nominal tensile strength of 180,000 PSI.
If you're putting a Small Block Chevy clutch assembly together, this is the kind of hardware you want to have on the bench before the transmission goes back in. ARP designed these pressure plate fasteners with an application-specific grip length, chromoly construction, and a large-diameter, low-profile head. It's a straightforward upgrade that gives a fresh clutch installation the proper high-performance fastener hardware.
ARP catalogs 130-2201 for Chevrolet 265-502 V8 applications, including Small Block 265, 283, 302, 305, 307, 327, 350 and 400 engines. For 1982-1992 Camaro and Firebird applications, verify that the vehicle is equipped with a compatible Small Block Chevrolet clutch and pressure plate using 3/8"-16 fasteners.
KEY FEATURES
- ARP High Performance Series pressure plate bolt kit
- ARP Part Number: 130-2201
- 3/8"-16 thread
- Hex-head design
- 9/16" wrench size
- 1.00" under-head length
- Premium chromoly construction
- 180,000 PSI nominal tensile strength
- Black oxide finish
- Large-diameter, low-profile head design
- Washers included
- Six bolts per kit
PRODUCT SPECIFICATIONS
| Specification | Details |
|---|---|
| Manufacturer | ARP |
| Part Number | 130-2201 |
| Product Type | Pressure Plate Bolt Kit |
| Application | Chevrolet V8 |
| Engine Range | Chevrolet 265-502 V8 |
| Thread Size | 3/8"-16 |
| Head Style | Hex |
| Wrench Size | 9/16" |
| Under-Head Length | 1.00" |
| Material | Chromoly |
| Finish | Black Oxide |
| Tensile Strength | 180,000 PSI nominal |
| Quantity | Set of 6 |
| Washers | Included |
| UPC | 672036001360 |
| Shipping Weight | 0.31 lb |
| Shipping Dimensions | 5.60" H × 2.80" W × 0.75" D |
VEHICLE FITMENT / FITS THE FOLLOWING MODELS
1982-1992 Chevrolet Camaro
- 1982-1992 Camaro
- Small Block Chevrolet V8 applications using a compatible 3/8"-16 pressure plate
1982-1992 Pontiac Firebird
- 1982-1992 Firebird
- Small Block Chevrolet V8 applications using a compatible 3/8"-16 pressure plate
Important: ARP's manufacturer application data identifies 130-2201 by Chevrolet engine application rather than by Camaro or Firebird model year. The 82-92 Camaro/Firebird vehicle application is therefore dependent on the specific SBC clutch and pressure plate configuration.
IMPORTANT APPLICATION NOTES AND EXCLUSIONS
- Designed for compatible Chevrolet V8 pressure plate applications using 3/8"-16 fasteners.
- Verify the pressure plate manufacturer's required thread size and fastener length before installation.
- This kit contains six bolts and washers.
- Do not assume this kit fits every Camaro or Firebird drivetrain configuration.
- Do not assume this kit is correct for LS applications. ARP lists separate pressure plate fasteners for Gen III/IV LS engines.
- ARP also lists a separate 134-2202 pressure plate bolt application for the 1992-1997 350 LT1.
- The 130-2201 should not be substituted for a pressure plate requiring a different thread size or grip length.
INSTALLATION NOTES
- Confirm the pressure plate requires 3/8"-16 fasteners before installation.
- Verify the 1.00" under-head length is appropriate for the specific clutch and flywheel combination.
- Clean the mating surfaces before assembly.
- Verify that the bolts do not bottom out in the flywheel.
- Check pressure plate and fastener clearance before final tightening.
- Tighten the pressure plate bolts according to the clutch manufacturer's recommended sequence and torque specification.
- Follow the latest ARP installation instructions and the pressure plate manufacturer's instructions.
FREQUENTLY ASKED QUESTIONS
What is ARP 130-2201?
ARP 130-2201 is a High Performance Series Chevrolet pressure plate bolt kit using 3/8"-16 hex-head fasteners. It is cataloged for Chevrolet 265-502 V8 applications.
How many bolts are included?
The kit contains six pressure plate bolts and washers.
What size thread does 130-2201 use?
The bolts use a 3/8"-16 thread.
What size wrench is required?
The hex head uses a 9/16" wrench.
What is the bolt length?
The verified under-head length is 1.00 inch.
What are these pressure plate bolts made from?
ARP identifies the fasteners as premium-grade chromoly with a nominal tensile strength of 180,000 PSI.
What finish do these bolts have?
The bolts feature a black oxide finish.
Will these fit an 82-92 Camaro or Firebird?
Hawks Motorsports lists 130-2201 specifically for 82-92 Camaro/Firebird SBC applications. The vehicle must have a compatible Small Block Chevrolet clutch and pressure plate requiring 3/8"-16 fasteners.
Will 130-2201 fit an LS engine?
Do not assume it will. ARP lists separate pressure plate bolt kits for Gen III/IV LS applications, using M10 x 1.50 threads.
Is 130-2201 the same application as the LT1 pressure plate bolt kit?
No. ARP catalogs 134-2202 separately for the 350 LT1 1992-1997 application.
