Product Description:
This used original GM dual electric cooling-fan assembly is designed for compatible 1993-1997 Chevrolet Camaro and Pontiac Firebird models equipped with the 5.7L LT1 V8 engine.
The assembly mounts behind the radiator and uses two electrically powered fans to draw air through the radiator when additional engine cooling is required. It provides an original-equipment replacement for a damaged, missing or inoperative factory LT1 fan assembly.
These are used original components, and the product photograph may be representative of available inventory. Cosmetic appearance, attached wiring and minor details may vary between assemblies.
| Feature | Product specification |
| Producer | General Motors |
| Product type | Radiator cooling-fan assembly |
| Vehicle platform | Fourth-generation GM F-Body |
| Model years | 1993-1997 |
| Engine application | 5.7L LT1 V8 |
| Fan configuration | Dual electric fans |
| Installation area | Behind the radiator |
| Condition | Used OEM GM |
| Regular price | $150.00 |
| Sale price | $75.00 |
| Discount | 50% off |
| Quantity | One assembly |
| Application | Required configuration |
| 1993-1997 Camaro Z28 |
5.7L LT1 V8 with compatible factory cooling system |
| 1996-1997 Camaro SS |
5.7L LT1 V8 with compatible factory cooling system |
| 1993-1997 Firebird Formula |
5.7L LT1 V8 with compatible factory cooling system |
| 1993-1997 Trans Am |
5.7L LT1 V8 with compatible factory cooling system |
This assembly is intended for LT1 V8 applications. Do not select it solely by model year or body style. Compare the shroud configuration, electrical connections, dimensions and attachment locations with the existing assembly before ordering.
- One used OEM GM dual electric cooling-fan assembly
- Factory molded radiator fan shroud
- Two electric cooling-fan motors
- Two fan blades and protective fan guards
- Attached components shown with the available assembly
Because these are used assemblies, attached connectors, wiring sections and other small components may vary. The product photograph may be representative rather than the exact unit shipped.
Factory LT1 Cooling Application
The dual electric fans draw air through the radiator when vehicle speed alone does not provide sufficient airflow. The vehicle's original cooling-fan electrical system controls fan operation according to engine temperature and operating conditions.
Original GM Configuration
The original assembly uses an application-specific shroud with two unequal fan sizes positioned within the molded housing. This layout is different from later LS1 fan assemblies and universal aftermarket dual-fan kits.
Used-Part Condition
Normal used-part characteristics may include scratches, scuffs, discoloration, dust, cleaning residue and other age-related cosmetic wear. Inspect the available product photographs when the exact appearance is important.
Cooling-System Diagnosis
A cooling fan that does not operate can also be caused by a fuse, relay, temperature input, electrical connector, damaged wiring, poor ground or control-system problem. Diagnose the vehicle before replacing the assembly and verify proper fan operation after installation.
- For compatible 1993-1997 LT1-equipped Camaro and Firebird models
- Designed for the factory-style dual electric cooling system
- Not intended for V6 applications
- Not intended for 1998-2002 LS1 cooling systems
- Compare the existing shroud and electrical connections before ordering
- Condition and appearance vary between used assemblies
- The displayed photograph may be representative
- Verify operation of both cooling fans after installation
- Allow the engine and cooling system to cool completely.
- Disconnect the negative battery cable before servicing the electric fans.
- Document the original assembly, wiring routing and connector positions.
- Disconnect the original fan electrical connections carefully.
- Remove the existing assembly without damaging the radiator or surrounding components.
- Compare the used replacement with the original fan assembly.
- Inspect the fan blades, guards, shroud, motors, wiring and connectors.
- Position the assembly without allowing the blades or shroud to contact the radiator.
- Reconnect the applicable factory electrical connections.
- Reconnect the battery and verify operation of both cooling fans.
Electric cooling fans can start automatically when commanded by the vehicle. Keep hands, clothing and tools away from the fan blades whenever the battery is connected.
What is the sale price?
The sale price is $75.00, a savings of $75.00 from the regular $150.00 price.
How much is the discount?
The sale price represents a 50% discount from the regular $150.00 price.
What vehicles does the assembly fit?
It is intended for compatible 1993-1997 Camaro and Firebird models equipped with the 5.7L LT1 V8 and factory-style dual electric cooling system.
Will it fit a Camaro Z28 or SS?
It fits compatible 1993-1997 Camaro Z28 and 1996-1997 Camaro SS models equipped with the LT1 V8 cooling configuration.
Will it fit a Firebird Formula or Trans Am?
It fits compatible 1993-1997 Firebird Formula and Trans Am models equipped with the LT1 V8.
Will it fit a V6 Camaro or Firebird?
No. This assembly is listed specifically for the LT1 V8 cooling application.
Will it fit a 1998-2002 LS1 vehicle?
No. The later LS1-equipped models use a different cooling-fan application.
Is this a new replacement assembly?
No. This is a used original GM cooling-fan assembly.
Will the assembly look exactly like the photograph?
Not necessarily. The photograph may be representative because multiple used assemblies may be available. Cosmetic condition and attached components can vary.
What should be checked before installation?
Inspect the shroud, fan blades, guards, motors, electrical connectors and wiring. Compare the replacement with the original assembly and test both fans after installation.
