Hawks Motorsports is pleased to offer our clients the following 434-6902 4.8L, 5.3L, 5.7L, 6.0L, 6.2L, 7.0L LS-Series Oil Pan Bolt Kit, 12-Point, Polished Stainless Steel, ARP. This ARP oil pan bolt kit is designed for Chevrolet Gen III/IV LS-Series applications and features polished stainless-steel construction, a compact 12-point head design and washers. ARP identifies 434-6902 specifically as a Gen III/IV LS-Series oil pan bolt kit.

When you're building an LS, the oil pan hardware might not be the first thing on the parts list—but once the engine is cleaned up and going back together, old rusty bolts stick out like a sore thumb. The polished stainless ARP hardware gives the bottom end that finished performance-engine look while the 12-point heads make working around the oil pan flange easier when space is tight. It's a small detail, but it's exactly the kind of detail a gearhead appreciates when the engine is on the stand and every fastener needs to look as good as the parts it's holding together.

The 434-6902 kit uses polished stainless-steel fasteners and includes washers. ARP's current documentation identifies this part number for Gen III/IV Chevrolet LS-Series blocks. The ARP LS/LT application guide specifically distinguishes 434-6902 from the similar 434-6901 hex-head LS-Series oil pan bolt kit and from the Gen V LT1/LT4 applications.

KEY FEATURES

• ARP Part Number: 434-6902
• LS-Series oil pan bolt kit
• Chevrolet Gen III/IV LS-Series application
• 12-point head design
• Polished stainless-steel construction
• Polished finish
• Washers included
• Designed for compatible LS-Series oil pan applications
• Compact 12-point head provides useful socket clearance around the oil pan flange
• Suitable for LS restoration, street-performance and engine-build applications

PRODUCT SPECIFICATIONS

ARP's current product page identifies 434-6902 as the LS1 LS2 stainless-steel 12-point oil pan bolt kit for Chevrolet Gen III and Gen IV LS-Series applications.

VEHICLE FITMENT / FITS THE FOLLOWING MODELS

Chevrolet Gen III/IV LS-Series Applications

Verified engine-family applications include:

• 4.8L LS-Series
• 5.3L LS-Series
• 5.7L LS1
• 6.0L LS-Series
• 6.2L LS-Series
• 7.0L LS7

Additional LS-family applications may include LS3, LS9, LSA, L76, L77, L98 and LSX configurations, but oil pan and block configuration should be verified before ordering.

Verified Vehicle Applications

Current Hawks and supporting application data identify LS-powered applications including:

• Chevrolet Camaro
• Chevrolet Corvette
• Pontiac Firebird
• Other Chevrolet Gen III/IV LS-powered applications

Hawks' current product page specifically associates the part with Camaro, Corvette and Firebird applications, while ARP's primary documentation defines the application by Gen III/IV LS-Series engine family rather than a universal vehicle-year list.

IMPORTANT APPLICATION NOTES AND EXCLUSIONS

• 434-6902 is a Gen III/IV LS-Series oil pan bolt kit.
• This is the 12-point polished stainless-steel version.
• The comparable LS-Series hex-head stainless-steel kit is 434-6901.
• Gen V LT1/LT4 blocks use different ARP oil pan bolt part numbers and should not be substituted with 434-6902.
• Oil pan and block configurations can vary between LS applications.
• Verify the engine block, oil pan configuration and fastener application before ordering.
• Do not assume every 4.8L, 5.3L, 5.7L, 6.0L, 6.2L or 7.0L engine uses the same oil pan configuration.

INSTALLATION NOTES

• Verify the oil pan and engine block configuration before installation.
• Clean and inspect the threaded holes before installing new fasteners.
• Test-fit the bolts to confirm proper thread engagement and clearance.
• Follow the oil pan manufacturer's recommended installation sequence and torque specifications.
• Follow ARP's recommended lubricant and torque procedures.
• Install the included washers as specified for the application.
• Tighten the oil pan fasteners evenly and in the recommended sequence to help maintain proper gasket sealing.
• Recheck the completed installation for proper clearance around the oil pan flange and surrounding components.
• Always follow the current ARP installation recommendations where applicable.

FREQUENTLY ASKED QUESTIONS

What engines does ARP 434-6902 fit?

ARP identifies 434-6902 for Chevrolet Gen III and Gen IV LS-Series engines. Common LS applications include 4.8L, 5.3L, 5.7L, 6.0L, 6.2L and 7.0L engines, subject to the specific block and oil pan configuration.

What type of head does 434-6902 use?

The 434-6902 uses a 12-point head design.

What material are these oil pan bolts made from?

The 434-6902 is the polished stainless-steel version of the Gen III/IV LS oil pan bolt kit. ARP identifies the stainless material as its proprietary ARP300 stainless material in its application guide.

Are washers included?

Yes. The 434-6902 bolt kit includes washers.

Does 434-6902 fit Gen V LT1/LT4 engines?

No. ARP lists separate oil pan bolt kits for Gen V LT1/LT4 blocks. The 434-6902 is identified for Gen III/IV LS-Series blocks.

What is the difference between ARP 434-6901 and 434-6902?

Both are polished stainless-steel Gen III/IV LS oil pan bolt kits. 434-6901 uses hex-head bolts, while 434-6902 uses 12-point heads.

Does the kit fit every LS oil pan?

Not necessarily. LS engine and oil pan configurations can vary. Verify the specific engine block and oil pan combination before ordering.
