Product Description:
C5 Z06 Chrome Staggered 17x9.5 / 18x10.5 Wheels, Set of 4, Replica
Hawks Motorsports offers our clients this C5 Z06 Chrome Staggered 17x9.5 / 18x10.5 Wheels Set of 4 Replica - 5353279 for upgrading the stance, appearance, and wheel profile of compatible Corvette, Camaro, Firebird, Formula, and Trans Am applications. This staggered wheel package includes two 17x9.5 front wheels and two 18x10.5 rear wheels, giving the vehicle a wider rear profile with a clean C5 Z06-inspired performance look.
These CV04-style chrome replica wheels provide the classic split-spoke C5 Z06 appearance with a bright chrome finish. The staggered sizing helps create a more aggressive rear stance while keeping the front wheel size controlled for steering clearance and street use. For owners wanting a polished performance look, this wheel set gives the car more flash without straying from the Corvette Z06 design language.
This set is a strong option for 1988-2004 Corvette applications, 1993-2002 Camaro and Firebird applications, and 1982-1992 Camaro / Firebird applications when proper wheel adapters are used. It is well suited for street cars, restoration upgrades, pro-touring styling, show vehicles, and F-body builds that need a brighter wheel package with factory-inspired geometry.
Chrome: Many myths surround the process of chrome plating. The majority of sellers out there have incorrect information and have not researched the process of chrome plating or spent time in plating facilities as OE Wheel Distributors has. We believe in research. Triple dipped or triple plated chroming is simply not the true process. The correct process lies within the preparation of the wheel prior to the plating. The first layer of plating is copper, which adheres to the wheel and creates a smooth foundation. The second layer is nickel, which provides the hardness or durability to the finish. The final layer is chrome, which creates the cosmetic finish. Just as important as this process is how long the wheel is left in the plating tank and how often the plating solution is replaced.
| Item ID | SET-CV04-18105-17095-56C |
| Wheel Size | 17x9.5 Fronts, 18x10.5 Rears |
| Wheel Offset | 54 Fronts, 56 Rear |
| Bolt Pattern | 5-120.65 |
| Hub Size | 70.3 |
| Back Spacing | NA |
| Center Caps | Center cap included, factory center cap will interchange. |
Features:
- C5 Z06-style replica wheel design
- CV04 wheel style
- Sold as a complete set of 4 wheels
- Staggered front and rear sizing
- Front wheel size: 17x9.5
- Rear wheel size: 18x10.5
- Finish: chrome
- Front wheel offset: 54mm
- Rear wheel offset: 56mm
- Bolt pattern: 5x120.65
- Hub size: 70.3mm
- Backspacing: N/A
- Center caps included
- Factory center caps are noted as interchangeable
- Bright chrome performance appearance
- Strong upgrade for compatible Corvette, Camaro, Firebird, Formula, and Trans Am applications
- Ideal for street cars, restoration upgrades, show builds, pro-touring styling, and performance appearance packages
Includes:
- Two 17x9.5 front wheels
- Two 18x10.5 rear wheels
- Center caps
- Wheels only unless otherwise specified
- Tires, lug nuts, valve stems, TPMS sensors, wheel adapters, and mounting / balancing are not included unless specifically listed
Fitment:
- 1988 Chevrolet Corvette
- 1989 Chevrolet Corvette
- 1990 Chevrolet Corvette
- 1991 Chevrolet Corvette
- 1992 Chevrolet Corvette
- 1993 Chevrolet Corvette
- 1994 Chevrolet Corvette
- 1995 Chevrolet Corvette
- 1996 Chevrolet Corvette
- 1997 Chevrolet Corvette
- 1998 Chevrolet Corvette
- 1999 Chevrolet Corvette
- 2000 Chevrolet Corvette
- 2001 Chevrolet Corvette
- 2002 Chevrolet Corvette
- 2003 Chevrolet Corvette
- 2004 Chevrolet Corvette
- 1993 Chevrolet Camaro
- 1994 Chevrolet Camaro
- 1995 Chevrolet Camaro
- 1996 Chevrolet Camaro
- 1997 Chevrolet Camaro
- 1998 Chevrolet Camaro
- 1999 Chevrolet Camaro
- 2000 Chevrolet Camaro
- 2001 Chevrolet Camaro
- 2002 Chevrolet Camaro
- 1993 Pontiac Firebird
- 1994 Pontiac Firebird
- 1995 Pontiac Firebird
- 1996 Pontiac Firebird
- 1997 Pontiac Firebird
- 1998 Pontiac Firebird
- 1999 Pontiac Firebird
- 2000 Pontiac Firebird
- 2001 Pontiac Firebird
- 2002 Pontiac Firebird
- 1993 Pontiac Formula
- 1994 Pontiac Formula
- 1995 Pontiac Formula
- 1996 Pontiac Formula
- 1997 Pontiac Formula
- 1998 Pontiac Formula
- 1999 Pontiac Formula
- 2000 Pontiac Formula
- 2001 Pontiac Formula
- 2002 Pontiac Formula
- 1993 Pontiac Trans Am
- 1994 Pontiac Trans Am
- 1995 Pontiac Trans Am
- 1996 Pontiac Trans Am
- 1997 Pontiac Trans Am
- 1998 Pontiac Trans Am
- 1999 Pontiac Trans Am
- 2000 Pontiac Trans Am
- 2001 Pontiac Trans Am
- 2002 Pontiac Trans Am
- 1982-1992 Chevrolet Camaro with proper wheel adapters
- 1982-1992 Pontiac Firebird / Trans Am with proper wheel adapters
Fitment Note:
- This is a staggered wheel set with 17x9.5 front wheels and 18x10.5 rear wheels.
- 1982-1992 Camaro and Firebird applications require proper wheel adapters.
- Staggered wheel packages normally require different front and rear tire sizes.
- Verify brake clearance, tire sizing, suspension setup, ride height, rear axle position, fender clearance, and inner wheelhouse clearance before installation.
- Clearance may vary by tire brand, brake package, suspension changes, alignment, ride height, and body condition.
- Lug nuts, tires, TPMS sensors, valve stems, wheel adapters, and mounting / balancing are not included unless specifically stated.
Vehicle Fitment: 88-2004 Corvette, 93-02 Camaro/Firebird, 82-92 Camaro/Firebird (must use wheel adapters)
