1982-1992 Chevrolet Camaro / Pontiac Firebird -Trans Am Sun Visor Pair, Hardtop or T-Top / Convertible New Reproduction, Acme Auto Headlining

Hawks Motorsports is pleased to offer our clients the following.

Refresh worn or damaged interior sun visors with a matching driver-side and passenger-side pair in foam-backed cloth. Select the roof style and fabric color to match the car; the hardtop and T-top/convertible versions use different visor patterns.

Choose the actual roof configuration. The broad 1982-1992 listing range identifies the third-generation platform; it does not mean convertibles were offered in every year. Acme specifically catalogs SV273 for 1987-1992 Camaro convertible applications. Earlier or altered convertible installations require comparison of the existing visor and supports.

• One driver-side sun visor in the selected fabric color
• One passenger-side sun visor in the same selected fabric color
• If the matching new-bracket add-on is selected: one pair of black sun visor brackets, supplied for the selected roof style

Visors Vary from Hardtop Version and GM Convertible and T-top Versions:

The hardtop visor pattern is separate then GM Convertible and T-top.

SV131 --Hard Tops: Feature a flat surface area.

SV273 -- GM Convertible and T-top: Feature a curved shape on the surface area.

* Note GM Convertibles 1987-1992 use SV273.

* Convertibles prior to 1987 or non-GM conversions may use the hard top instead check your application.

Both choices in this Hawks listing are mirrorless and supplied as a pair.

Visors Posts vary from Hardtop Version and GM Convertible and T-top Versions:

Due to the angle on the roof line mounting area between Hard Top and Convertible /T-top roof cars use different sun visors posts Use the code below when selecting your roof style.

BRKT78-BLACK - For use on Hard Top equipped cars

BRKT81-BLACK - For use on GM Convertible and T-top model cars

Visor Tension Screw Information

With the visors folded up, the passenger-side set-screw head faces down and is visible; the driver-side set-screw head faces up and is concealed. This is the documented left/right arrangement.

Available Colors / Important info.

*Sand Gray code 2126 is restricted by the current Hawks option to 1982-1984 cars. Select another listed color for later years.

Picking the right color for your car's needs: Color names alone may not identify the correct interior shade. Your computer monitor color setting will affect the colors as shown from the actual material. If you are simply not sure of what color you need, please feel free to request a color sample from Hawks Motorsports

Email us at Sales@Hawksmotorsports.com

Include the following information with your request:

Your name, mailing address, telephone #

Color code	Current Hawks color option
1559	Black
2001	Charcoal
1755	Light Saddle
1666	Burgundy
1872	Red
1714	Maple
2092	Navy Blue
1810	Medium Dark Gray
2126 v	Sand Gray (1982-1984 cars only)

Compare the original visor shape, pivot mounting position and selected roof style before installation. Inspect the bracket, fixed pin and sleeve for wear or movement.

Position the driver-side and passenger-side visors according to the set-screw orientation described above. Follow the vehicle service procedure when securing the supports.

Check each visor through its normal stowed and lowered positions and confirm clearance at the roof trim and windshield header.

Which style should I select for my roof?

Select Hard Top SV131 for a solid-roof car, or T-Top / Convertible SV273 for the matching open-roof configuration.

Why do the two set screws look different when the visors are up?

The passenger screw faces down and is visible, while the driver screw faces up and is concealed. This is the documented pair orientation.

Which new bracket option matches a hardtop?

The hardtop application uses the BRKT78-BLACK bracket pair. T-top and compatible convertible applications use BRKT81-BLACK.

How can I check the fabric shade before ordering if I really don't know my color?

Request samples from Hawks and compare the color codes with the vehicle interior in suitable light.

What delivery time should I plan for?

The current Hawks page states custom production with an estimated 7-8 weeks for delivery. Confirm timing when placing the order.
