Product Description:
Hawks Motorsports is pleased to offer our clients this 1991-1992 Chevrolet Camaro Z28 17x9 Red Wheel Individual from Hawks Restoration Parts, part number HT179Z28R-I. This reproduction wheel brings the classic 1991-1992 Camaro Z28 styling into a wider 17x9 package, with a red finish, 5x4.75 bolt pattern, +12mm offset, and 5.5-inch backspacing. The corresponding HT179Z28R wheel is documented for 1982-1992 Camaro and Firebird applications.
This is the wheel for the third-gen crowd that wants the right look without settling for skinny factory sizing. The five-spoke Z28 design still screams early-'90s F-body, but the 17x9 footprint gives the car a much more serious stance. Whether you're replacing one damaged wheel, piecing together a set, or building a nasty third-gen street car, bolt one on, get the tires mounted, and get after it.
KEY FEATURES
- Hawks Restoration Parts reproduction wheel
- Individual wheel
- 17x9 wheel size
- Red finish
- 1991-1992 Camaro Z28 styling
- Five-spoke Z28 design
- 5 x 4.75-inch bolt pattern
- +12mm offset
- 5.5-inch backspacing
- Approximately 28.4 lbs per wheel without center cap
- Designed for 1982-1992 Camaro and Firebird applications
- Two front wheel spacers are documented with the corresponding wheel package for applicable third-generation F-body installations
- Commonly recommended tire size: 275/40R17
- Wheels-only configuration; center caps, lug nuts and valve stems are separate unless specifically included
PRODUCT SPECIFICATIONS
- Manufacturer: Hawks Restoration Parts
- Product Type: Wheel
- Current Part Number: HT179Z28R-I
- Related Set Part Number: HT179Z28R
- Size: 17x9
- Finish: Red
- Style: 1991-1992 Camaro Z28
- Bolt Pattern: 5 x 4.75 inches
- Offset: +12mm
- Backspacing: 5.5 inches
- Approx. Wheel Weight: 28.4 lbs without center cap
- Quantity: 1
- Condition: New reproduction
The underlying HT179Z28R specifications are documented by Hawks and JEGS.
VEHICLE FITMENT
Chevrolet Camaro
- 1982-1992 Chevrolet Camaro
- 1982-1992 Camaro Z28
- 1985-1990 Camaro IROC-Z
- 1989-1992 Camaro RS
Pontiac Firebird
- 1982-1992 Pontiac Firebird
The current Hawks listing identifies the HT179Z28R wheel for 1982-1992 Camaro and Firebird applications.
IMPORTANT APPLICATION NOTES AND EXCLUSIONS
- This listing is for ONE individual wheel.
- The wheel is based on the appearance of the 1991-1992 Z28 factory 16x8 wheel but is upsized to 17x9.
- The corresponding wheel uses a 5x4.75 bolt pattern, +12mm offset and 5.5-inch backspacing.
- Hawks documents two front wheel spacers with the wheel package for proper front fitment on applicable third-generation F-body installations.
- Final brake, suspension, tire and fender clearance should be verified on the individual vehicle.
- 275/40R17 is the commonly recommended tire size for this wheel package, but final tire selection should be confirmed for the specific vehicle setup.
- This individual wheels-only listing should not be assumed to include center caps, lug nuts, lug nut caps or valve stems.
INSTALLATION NOTES
- Test-fit the wheel before mounting the tire.
- Verify brake-caliper and suspension clearance.
- Verify tire-to-fender and wheel-opening clearance at normal ride height and through suspension travel.
- Confirm front spacer requirements before final installation.
- Use appropriate lug nuts for the wheel and vehicle.
- Torque wheel hardware to the vehicle manufacturer's specification.
- If replacing one wheel, compare the existing wheel's size, offset, backspacing and finish before ordering.
FREQUENTLY ASKED QUESTIONS
Is this for one wheel or four wheels?
This listing is for one individual 17x9 red wheel.
What size is the wheel?
17x9.
What is the bolt pattern?
5 x 4.75 inches.
What are the offset and backspacing?
+12mm offset and 5.5-inch backspacing.
Will it fit a 1982-1992 Camaro?
The corresponding HT179Z28R wheel is listed for 1982-1992 Camaro applications. Vehicle-specific clearance should still be checked.
Will it fit a 1982-1992 Firebird?
Yes. Hawks lists the corresponding wheel for 1982-1992 Firebird applications.
Is this the original factory wheel size?
No. The styling is based on the 1991-1992 Z28 wheel, but this reproduction is upsized to 17x9 from the original 16x8 configuration.
What tire size is commonly recommended?
275/40R17 is the commonly listed recommendation for this wheel package.
Are center caps included?
No. This is an individual wheels-only listing. Center caps are separate unless specifically included with the selected product configuration.
Are lug nuts included?
No. Do not assume the lug nuts supplied with the complete wheel kit are included with this individual wheel.
Are front spacers required?
Hawks documents two front spacers with the corresponding wheel package for proper fitment on applicable third-generation F-body installations.
