Hawks Motorsports offers our clients this 850 LSX 6-Rib Harmonic Balancer for 2006-2013 Corvette LS7, Standard Diameter, Innovators West. This SFI 18.1 harmonic balancer is designed for the LS7 Corvette and features a 6-rib drive with the standard 7.25-inch pulley diameter. A crank bolt and single 3/16-inch keyway are included.

For an LS7 that needs a solid crank damper without changing the factory belt ratio, this is the straightforward way to go. The 6-rib pulley keeps the accessory drive familiar while the SFI-rated damper gives a serious engine build the kind of crankshaft control you want when the RPM starts climbing. It's a clean choice for a naturally aspirated LS7, road-race setup, street car, or a build where you're sticking with the factory-style 6-rib drive.

The 7.25-inch standard diameter keeps the stock pulley ratio, and the balancer weighs approximately 7.4 lbs. It comes with a single 3/16-inch keyway and can be ordered with an optional second keyway for applications that require additional crankshaft retention.

KEY FEATURES:

• Part number: 850
• Innovators West harmonic balancer
• Designed for LS7 Corvette applications
• 6-rib belt drive
• 7.25-inch standard diameter
• Approximately 7.4 lbs
• Exceeds SFI 18.1 standards
• Single 3/16-inch keyway
• Crank bolt included
• Designed for the Corvette LS7 accessory-drive configuration
• Optional dual-keyway configuration available
• Suitable for high-performance LS7 applications

FITMENT APPLICATIONS:

Chevrolet Corvette Z06 — 7.0L LS7

• 2006 Chevrolet Corvette Z06
• 2007 Chevrolet Corvette Z06
• 2008 Chevrolet Corvette Z06
• 2009 Chevrolet Corvette Z06
• 2010 Chevrolet Corvette Z06
• 2011 Chevrolet Corvette Z06
• 2012 Chevrolet Corvette Z06
• 2013 Chevrolet Corvette Z06

Chevrolet Corvette Grand Sport — LS7

• 2010 Chevrolet Corvette Grand Sport
• 2011 Chevrolet Corvette Grand Sport
• 2012 Chevrolet Corvette Grand Sport
• 2013 Chevrolet Corvette Grand Sport

Innovators West identifies this damper for GM 2006-2013 LS7 Corvette applications.

INSTALLATION NOTES:

• This listing is for one 850 harmonic balancer.
• Crank bolt is included.
• Verify engine and accessory-drive configuration before ordering.
• Designed for a 6-rib belt drive.
• The standard 7.25-inch diameter maintains the standard crank/accessory-drive ratio.
• The damper comes with a single 3/16-inch keyway.
• An optional second 3/16-inch keyway is available; the crankshaft must be machined for the second keyway 180° from the original.
• Do not install a dual-keyway damper on a crankshaft that has not been properly machined and double-keyed.
• Verify crankshaft snout and keyway condition before installation.
• Use the proper harmonic damper installation tool.
• Follow the manufacturer's installation and torque specifications.
• Verify pulley alignment and belt tracking before operating the engine.
• Do not modify or permanently install the damper until fitment has been confirmed.
