Hawks Motorsports offers our clients this 905-KIT LS7 Corvette 10-Rib Drive Conversion Kit with 10% Overdrive Damper, Innovators West. This kit converts the compatible LS7 Corvette accessory drive to a 10-rib belt system and includes a 10% overdrive harmonic damper.

If you're building an LS7 that's making more power than GM ever intended, the factory belt drive can become part of the weak link. The 10-rib conversion puts considerably more belt on the pulleys, helping keep the drive hooked up when a supercharger starts putting some serious load through the front of the engine. The 10% overdrive damper then adds crank speed to the equation, giving a blower combination more room to make power without relying entirely on a tiny supercharger pulley.

The 905 conversion uses an 8.0-inch, 10-rib, 10% overdrive damper and is designed specifically around the LS7 Corvette accessory-drive arrangement. The kit is intended for high-performance and forced-induction LS7 combinations where belt control and additional supercharger speed are priorities.

KEY FEATURES:

• Part number: 905-KIT
• Innovators West 10-rib drive conversion kit
• Designed for LS7 Corvette applications
• 10% overdrive harmonic damper
• 8.0-inch damper diameter
• 10-rib accessory drive
• SFI 18.1 performance damper
• Designed for high-performance and forced-induction applications
• Increased belt contact compared with a factory-style 6-rib setup
• Designed specifically around the LS7 Corvette accessory drive
• Optional crank pin and blower-hub components available depending on application

FITMENT APPLICATIONS:

Chevrolet Corvette LS7

• 2006 Chevrolet Corvette Z06 — 7.0L LS7
• 2007 Chevrolet Corvette Z06 — 7.0L LS7
• 2008 Chevrolet Corvette Z06 — 7.0L LS7
• 2009 Chevrolet Corvette Z06 — 7.0L LS7
• 2010 Chevrolet Corvette Z06 — 7.0L LS7
• 2011 Chevrolet Corvette Z06 — 7.0L LS7
• 2012 Chevrolet Corvette Z06 — 7.0L LS7
• 2013 Chevrolet Corvette Z06 — 7.0L LS7

Important: Verify the engine and accessory-drive configuration before ordering. This kit is intended for the LS7 Corvette accessory drive and should not be assumed to fit other LS engines simply because they share the LS architecture.

INSTALLATION NOTES:

• This listing is for one 905-KIT 10-rib drive conversion kit.
• Verify the vehicle, engine and accessory-drive configuration before ordering.
• The kit converts the applicable LS7 accessory drive to a 10-rib belt system.
• The included damper provides 10% crankshaft overdrive.
• Verify belt length and routing after conversion.
• Verify pulley alignment across the entire accessory drive.
• Inspect the crankshaft snout and keyway before installing the damper.
• A crankshaft pin kit may be required depending on the crankshaft and damper configuration.
• Follow Innovators West installation and torque specifications.
• Forced-induction applications should account for the increased supercharger speed created by the 10% overdrive ratio.
• Verify the complete belt-drive combination before starting the engine.
• Do not modify or permanently install components until fitment has been confirmed.
• Professional installation is recommended.
